MIW-XT

Max-In-Wall Power & Signal Bay, 15A Code Compliant Extension System

MIW-XT extends noise free, safe power from Panamax / Furman Power Management components to remote panel displays, ceiling mounted video projectors and powered sub-woofers.

Description

MIW-XT extends noise free, safe power from Panamax / Furman Power Management components to remote panel displays, ceiling mounted video projectors and powered sub-woofers. Discreetly hides behind electronic equipment for a neat, clean, code compliant and professional installation.

Features

  • Ultra-thin profile can allow equipment to hang less than one inch from the wall.
  • EMI/RFI noise filtration built into outlet receptacle.
  • Power and signal lines are hidden in the wall behind panel displays for a clean, tidy and professional installation.
  • Extend Connected Equipment Policy to remote equipment when used with Panamax/Furman Power Management components.
  • Accommodates optional MIW Signal Line Modules (sold separately, contact Panamax or Furman).
  • CSA Certified for code compliant installations.
  • 3 Year Product Warranty

Compatibility Chart

New Work Old Work
Plastic Carlon SC200DV Carlon B114R
Metal Raco 8355 Raco 508
(hardware removed)

Other Specifications

General
  • FamilyIn Wall
  • Line Voltage120 (Volts)
  • Number of Outlets1
  • Outlet Descriptions1 filtered outlet
  • ComplianceCSA
  • USB ChargingN/A
  • Low Voltage TriggerN/A
  • AC Power Cord6 ft. detachable inlet power cord. 11 inch flat plug output cord.
  • Dimensions4.75" W x 0.25" D x 4.75" H
AC Protection
  • AC Protection TechnologyN/A
  • Undervoltage ShutoffN/A
  • Over-Voltage ShutoffN/A
  • Maximum Current Rating15 (Amps)
  • Initial Clamping LevelN/A
Filtration
  • Filtration TechnologyRFI/EMI Filtration
  • Signal Line ProtectionNo
Shipping Info
  • Length7.7 (Inches)
  • Width5.2 (Inches)
  • Height6.9 (Inches)
  • Weight2.9 (Lbs)
  • Unit of MeasureEach
  • UPC050616008488
  • Master Pack Qty6

Warranty

3 YEAR PRODUCT WARRANTY

Panamax warrants to the purchaser of this Panamax audio/video component style power conditioner, for a period of three (3) years from the date of purchase, that the unit shall be free of any defects in design, material or workmanship, and Panamax will repair or replace any defective product up to three years from the purchase date.

WARRANTY LIMITATION FOR INTERNET PURCHASERS:

Panamax products purchased through the Internet do not carry a valid Connected Equipment Protection Policy unless purchased from an Authorized Panamax Internet Dealer! Authorized Panamax Internet Dealers have sufficient expertise to insure warranty compliant installations.
